10KH17N13M2T ( 10Х17Н13М2Т ) ( Х17Н13М2Т ЭИ448 )
10X17H13M2T Stainless Steel Pipes in India — Russian Metals
Your trusted supplier of industrial 10X17H13M2T steel for chemical equipment, aerospace, and marine applications.
INTRODUCTION OF 10X17H13M2T
10X17H13M2T (Russian GOST 10Х17Н13М2Т, also known as AISI 316Ti / EN 1.4571) is a high-alloy austenitic stainless steel stabilized with titanium. It combines excellent corrosion resistance, high mechanical strength, and long-term heat resistance. This grade is widely used for chemical processing equipment, heat exchangers, and piping systems where aggressive media and elevated temperatures are present.
| Grade : | 10KH17N13M2T ( 10Х17Н13М2Т ) ( Х17Н13М2Т ЭИ448 ) |
| Classification : | Corrosion-resistant steel for general purposes |
10X17H13M2T — Chemical Composition
| Element | Min (%) | Max (%) |
|---|---|---|
| C | – | 0.10 |
| Si | – | 0.80 |
| Mn | – | 2.00 |
| P | – | 0.035 |
| S | – | 0.020 |
| Cr | 16.00 | 18.00 |
| Ni | 12.00 | 14.00 |
| Mo | 2.00 | 3.00 |
| Ti | ≥5×C | 0.70 |
Mechanical properties under Т=20oС for grade 12KH18N10T ( 12Х18Н10Т )
| Assortment | Dimension | Direct. | σB | σT | δ5 | ψ | KCU | Heat treatment |
|---|---|---|---|---|---|---|---|---|
| - | (mm) | - | MPa | MPa | % | % | kJ/m² | - |
| Pipe cooling strain, GOST 9941-81 | 549 | 35 | ||||||
| Pipe hot strain, GOST 9940-81 | 529 | 40 | ||||||
| Bar, GOST 5949-75 | to Ø 60 | 510 | 196 | 40 | 55 | Guenching 1020 - 1100oC,Cooling air, | ||
| Wire, GOST 18143-72 | 540-830 | 20-25 | ||||||
| Forging, GOST 25054-81 | to 1000 | 510 | 196 | 35-38 | 40-52 | Guenching 1050 - 1100oC, water, | ||
| Sheet trick, GOST 7350-77 | 530 | 235 | 38 | Guenching 1000 - 1080oC,Cooling water, | ||||
| Sheet thin, GOST 5582-75 | 530 | 205 | 40 | Guenching 1050 - 1080oC,Cooling water, | ||||
| Sheet thin cold-worked , GOST 5582-75 | 880-1080 | 10 | ||||||
| Sheet thin, GOST 5582-75 | 740 | 25 |
Mechanical & Physical Properties
| Property | Typical Values |
|---|---|
| Tensile Strength (Rm) | 500–700 MPa |
| Yield Strength (Rp0.2) | ~215–250 MPa |
| Elongation (A5) | ≥35% |
| Impact Toughness (KV) | High at room & low temp |
| Hardness | ≤ 200 HB (~90 HRB) |
| Density | ~7.95 g/cm³ |
| Max Service Temp | ~600°C (heat resistant) |
Weldability
Excellent — welding possible without preheating or post-weld heat treatment.
Heat Treatment
Solution anneal ~1050–1100°C followed by rapid cooling.
Heat & Corrosion Resistance
Corrosion Resistance
- Resists oxidation and scaling up to ~600°C in continuous service.
- Superior pitting & crevice corrosion resistance due to Mo + Ti stabilization.
- Excellent in chloride-rich chemical and marine environments.
Applications of 10X17H13M2T
Industrial Chemical Equipment
Used in tanks, columns, heat exchangers, and evaporators.
Pipes & Tubing
Ideal for marine, oil & gas, and petrochemical plants.
Food & Pharmaceutical Industry
Used where hygiene & corrosion resistance are critical.
Power & Energy Sector
Used in superheater tubes, boiler piping, and exhaust manifolds.
Aerospace & Cryogenic Systems
Needed for strength and stability at variable temperatures.
Available Forms & Services — Russian Metals
- Seamless & Welded Pipes/Tubes: OD 6–630 mm; custom wall thickness.
- Plates & Sheets: HR / CR, cut-to-size.
- Bars & Rods: Forged, turned or ground finish.
- Coils & Strips: Precision slit edges.
- Fittings & Flanges: Per ANSI / DIN / GOST.
- Value-Added Services: Cutting, bending, CNC machining, polishing, passivation, export packaging.
We supply industrial 10X17H13M2T steel for chemical equipment with full mill test certificates (MTC) and global shipping support.
Equivalent & Comparable Grades
EN:
X6CrNiMoTi17-12-2 (1.4571)
AISI / ASTM:
316Ti
JIS:
SUS316Ti
Other:
0Cr18Ni12Mo2Ti (GB), H17N13M2T
(Always verify MTCs when substituting for critical designs.)
Why Choose Russian Metals?
- Premium Certified: 10X17H13M2T pipes & products, ready for industrial chemical equipment.
- Wide Stock Range: Seamless tubes, plates, coils, fittings, flanges.
- Expert Guidance: Grade selection & design advice for aggressive chemical service.
- Fast Delivery: Across India & worldwide exports.
Types of delivery of grade 09G2S ( 09Г2С )
- B03 - Metal forming treatment. Forgings
- В22 - Graded and shaped rolling
- B23 - Sheets and Strips
- В32 - Graded and shaped rolling
- B33 - Sheets and Strips
Specification
Mechanical properties :
σB - Tensile strength [MPa]
σT - Yield stress [MPa]
δ5 - Specific elongation at fracture [%]
ψ - Reduction of area [%]
KCU - Impact strength [kJ/m²]
HB - Brinell hardness [MPa]
Physical properties :
T - Test temperature [Grade]
E - Young modulus [MPa]
α - Coefficient of linear expansion (20° - T) [1/Grade]
λ - Thermal (heat) condition coefficient [Watt/(m·Grade)]
ρ - Density [kg/m³]
C - Specific heat (range 20° - T) [J/(kg·Grade)]
R - Electrical resistance [Ohm·m]
Weldability :
without limitations - welding is done without heating and subsequent heat treeting
limited weldability - welding is possible under heating up to 100-120 grade and subsequent heat treeting
hard weldability - obtaining the quality welding needs the additional operations:heating up to 200-300 grade; the heat treeting ia annealing
